Console de mixage Premium 32 canaux
- 24 entrées micro avec alimentation fantôme 48V et filtre passe-haut par canal
- 32 entrées ligne (24 mono et 4 stéréo)
- 6 envois Aux / 2 envois FX
- 4 bus GROUP + bus ST
- 2 sorties MATRIX
- 1 sortie MONO avec filtre passe-bas commutable et réglable
| MGP32X | ||
|---|---|---|
| Mixing capability | Mixing channels | 32 Line Inputs (24 mono and 4 stereo) |
| GROUP | 4 GROUP Buses + ST Bus | |
| AUX | 6 AUX Sends + 2 FX Sends | |
| MATRIX | 1 Matrix out | |
| On-board processors | FX1:REV-X(8 PROGRAM, PARAMETER control)/ FX2:SPX(16 PROGRAM, PARAMETER control) | |
| Input channel functions | - | |
| I/O | Mic inputs | MIC: 24 (INPUTS HPF: 100Hz 12dB/oct) |
| Phantom power | 48V phantom power per channel | |
| Line inputs | LINE: 24 mono + 4 stereo, CH INSERT: 24 RETURN: 1 stereo | |
| Digital I/O | USB Device, iPod / iPhone | |
| Total harmonic distortion | 0.02% (20Hz-20kHz@ +14dBu) | |
| Frequency response | +0.5/-1.0dB 20Hz - 20kHz, refer to the nominal output level @1kHz | |
| Hum & noise level | Equivalent input noise | -128 dBu Equivalent Input Noise |
| Residual output noise | -92 dBu Residual Output Noise | |
| Crosstalk | -74dB @ 1kHz | |
| Besoins en énergie | 100-240V 50Hz/60Hz | |
| Consommation électrique | 86W max | |
| Dimensions | W | 1,027mm (40.4") |
| H | 169mm (6.7") | |
| D | 565mm (22.2") | |
| Poids net: | 19kg (41.9lb) | |
